·ABSOLUTE MAXIMUM RATINGS(Ta=25℃)
SYMBOL PARAMETER VALUE UNIT
VDSS Drain-Source Voltage 60 V
VGS Gate-Source Voltage ±20 V
ID Drain Current-Continuous 95 A
IDM Drain Current-Single Pulsed 380 A
PD Total Dissipation @TC=25℃ 125 W
Tj Max. Operating Junction Temperature 175 ℃
Tstg Storage Temperature -55~175 ℃
DESCRITION
Reliable device for use in a wide variety of applications.
FEATURES
·Static drain-source on-resistance:
RDS(on) ≤5.9mΩ
·Enhancement mode.
·Fast Switching Speed.
·100% avalanche tested.
·Minimum Lot-to-Lot variations for robust device performance and reliable operation.
