MOX1 MediceL® Sensor
Poisoning
CiTiceLs are designed for operation in a wide range of environments and harsh conditions. However, it is important that exposure to high concentrations of solvent vapours is avoided, both during storage, fitting into instruments and operation.
When using sensors with printed circuit boards (PCBs), degreasing agents should be used before the
sensor is fitted. Do not glue directly on or near the CiTiceL as the solvent may cause crazing of the plastic.
Intended Use
These sensors are designed to be used to monitor the partial pressure of oxygen in anaesthesia (not including xenon), critical care, neonatal incubators, and general oxygen monitors.
Stabilisation Time
Allow at least 15 minutes to stabilise in the instrument before calibration or refer to manufacturers instructions.
Cleaning and Sterilisation
In case of contamination the sensor may be cleaned with distilled water and allowed to dry naturally. The sensor is not suitable for sterilisation by steam or exposure to chemicals such as ethylene oxide or hydrogen peroxide.
Calibration Interval
These sensors are designed to have minimal drift over their useful lifetime. For maximum accuracy however they should be calibrated before each use.
If the Sensor is Dropped
If a sensor is dropped, then it should be placed in quarantine for 24 hours and a follow-up check made by a 2 point calibration.
Mechanical Installation
When installing the sensor, it must only be screwed in hand-tight and a gas tight seal ensured. Spanners and similar mechanical aids may not be used, as excessive force may damage the sensor thread.
RFI/EMI Susceptibility
MediceLs contain metal and may be susceptible to RFI or EMI. They are not suitable for use in MRI environments. For further information please contact City Technology.
Cross Sensitivity
The table below shows how MOX1 MediceLs respond when tested with the gas mixtures listed in ISO 80601-2-55.
Test Gas | % O2 Error |
50% He / 50% O2 | < 1% |
60% N2O / 40% O2 | < 1% |
2% Halothane / 40% O2 / 30% N20 / 5% CO2 / Bal N2 | < 1.5% |
2% Enflurane / 40% O2 / 30% N20 / 5% CO2 / Bal N2 | < 1.5% |
2% Isoflurane / 40% O2 / 30% N2 0 / 5% CO2 / Bal N2 | < 1.5% |
Key Features and Benefits
Meets the requirements of ISO 80601-2-55 | Linear output from 0 % to 100 % O2 | 13-month warranty | RoHS compliant |
TECHNICAL SPECIFICATIONS |
|
| MEASUREMENT | |
| Operating Principle | Partial pressure electrochemical |
| Output | 9 mV to 13 mV in 210 mBar O2 |
| Measurement Range | 0 mBar to 1500 mBar O2 |
| Response Time (T90) | <15 s (air to 100% O2) |
| Baseline Offset | <200 μV |
| Linearity | Linear 0% to 100% O2 (See Note1) |
| ELECTRICAL | |
| Temperature Compensation | <2% O2 equivalent (0°C to 40°C) |
| External Load Resistor | 10 kΩ minimum (See Important Note) |
| Connector | 3-pin Molex Header: (Molex 22-29-2031) |
| Recommended Mating Part | Molex Housing: (Molex 22-01-2035) Molex Crimp Terminals (Molex 08-45-0110) |
| MECHANICAL | |
| Housing Material | White ABS |
| Weight | 39 g (nominal) |
| Orientation | Any |
| ENVIRONMENTAL | |
| Typical Applications | Critical care anesthesia |
| Operating Temperature Range | -20°C to +50°C |
| Operating Pressure Range | 0.5 Bar to 2.0 Bar |
| Operating Humidity Range | 0% to 99% RH non- condensing |
| LIFETIME | |
| Long-Term Ouput Drift in 100% O2 | < 5% signal loss/year |
| Recommended Storage Temperature | -10°C to +40°C |
| Expected Operating Life: @ 20°C @ 40°C | 1.5 x 106 % O2 hours 0.8 x 106 % O2 hours |
| Packaging | Sealed blister |
| Standard Warranty | 13 months from date of despatch (This amounts to a variation of condition 6 of our standard terms and conditions which otherwise apply) |
